aut.vn Bộ nguồn xung Omron S8AS-48008

Power rating : 480 W
Output voltage : 24 VDC
Rated input voltage : 100 to 240 VAC
Construction : Covered type
Connection : Terminal blocks
Terminal type : Screw terminal, Screwless terminal
Power rating : 480 W
Output voltage : 24 VDC
Efficiency : 80 % typ.
Input : Rated input voltage : 100 to 240 VAC
Allowable input voltage variable range : 85 to 264 VAC
Frequency : 50/60Hz (47 to 63 Hz)
Rated input current : 7.4 A max. (at 100 VAC input)
3.9 A max. (at 200 VAC input)
Power factor : 0.95 min.
Leakage current : 0.5 mA max. (at 100 VAC input)
1 mA max. (at 200 VAC input)
Inrush current (cold start at 25 ℃) : 25 A max. (at 100 VAC input)
50 A max. (at 200 VAC input)
Output : Rated output current : 20 A
Output voltage variable range : ±10 % (With V.ADJ)
Ripple : 2 %(p-p) max.
Static input variation influence : 0.5 % max. (at 100% load)
Static load variation influence : 4.0 % max. (at rated input, 0 to 100% load)
Ambient temperature variation influence : 0.05 %/℃ max.
Start up time : 3000 ms max.
Hold time : 20 ms min.
Additional functions : Series operation : No
Parallel operation : No
Output indicator : Yes (color: green)
Output voltage indication : Yes
Output current indication : Yes
Maintenance forecast monitor : Output: Yes (photoswitch output, 30 VDC max., 50 mA max., Leakage current: 0.1 mA max., Residual voltage: 2 V max.)
Undervoltage alarm : Output: Yes (photoswitch output, 30 VDC max., 50 mA max., Leakage current: 0.1 mA max., Residual voltage: 2 V max.)
Indication: Yes
Insulation : Dielectric strength : Between all input terminals and all branch outputs/all I/O signals/all communications terminals: 3 kVAC for 1 min, Detection current: 20 mA
Between all input terminals and PE terminals: 2 kVAC for 1 min, Detection current: 20 mA
Between all branch outputs/all I/O signals/all communications and PE terminals: 1 kVAC for 1 min, Detection current: 20 mA
Between all branch outputs/all I/O signals and all communications terminals: 500 VAC for 1 min, Detection current: 20 mA
Between all I/O signals and all communications: 500 VAC for 1 min, Detection current: 20 mA
Between all input signals and all output signals: 500 VAC for 1 min, Detection current: 20 mA
Insulation resistance : Between all branch outputs/all I/O signals/all communications terminals and all input terminals/PE terminals: 100 MΩ min., at 500 VDC
Environment : Vibration resistance : 10 to 55 Hz, 0.375 mm single amplitude in each 3 directions for 2 hours
Shock resistance : 150 m/s2, in each 6 directions 3 times
Ambient temperature (Operating) : -10 to 60 ℃ (with no freezing or condensation)
Ambient temperature (Storage) : -25 to 65 ℃
Ambient humidity (Operating) : 25 to 85 %
Ambient humidity (Storage) : 25 to 90 %
Reliability : Life expectancy : 10 years (at rated input, a load rate of 50% load, under the temperature of 40 ℃, standard mounting)
Construction : Construction : Covered type
Connection : Terminal blocks
Terminal type : Screw terminal, Screwless terminal
Mounting : DIN track mounting
Weight (Main) : 2400 g max.
