Cảm biến tiệm cận là một loại cảm biến điện tử nhận biết sự hiện diện của vật thể mà không cần tiếp xúc vật lý. Chúng hoạt động dựa trên việc phát hiện sự thay đổi trong trường điện từ, từ trường hoặc sóng âm. Khi một vật thể tiến gần đến cảm biến, trường bị ảnh hưởng, kích hoạt tín hiệu. Cảm biến tiệm cận được ứng dụng trong nhiều lĩnh vực như tự động hóa, robot, điều khiển, và bảo mật.
Cảm Biến Tiệm Cận Autonics PRDT18-7DO-M18-7mm-250Hz-Normally Open
Wire type and power : DC 2-wire type 12-24VDC @(=)
Sensing side diameter : M18
Sensing distance : 7mm
Installation : Shield(flush)
Standard sensing target : 20×20×1mm(iron)
Response frequency : 250Hz
Cảm Biến Tiệm Cận Autonics PR12-4DP2-M12-4mm-500Hz-PNP Normally Closed
Wire type and power : DC 3-wire type 12-24VDC @(=)
Sensing side diameter : M12
Sensing distance : 4mm
Installation : Non-flush
Standard sensing target : 12×12×1mm(iron)
Response frequency : 500Hz
Cảm Biến Tiệm Cận Autonics PRT12-4DC-M12-4mm-500Hz-Normally Closed
Wire type and power : DC 2-wire type 12-24VDC @(=)
Sensing side diameter : M12
Sensing distance : 4mm
Installation : Non-flush
Standard sensing target : 12×12×1mm(iron)
Response frequency : 500Hz
Cảm Biến Tiệm Cận Autonics PRS12-4DN-M12-4mm-500Hz-NPN Normally Open
Wire type and power : DC 3-wire type 12-24VDC @(=)
Sensing side diameter : M12
Sensing distance : 4mm
Installation : Non-flush
Standard sensing target : 12×12×1mm(iron)
Response frequency : 500Hz
Cảm Biến Tiệm Cận Autonics PRDT18-14DC-M18-14mm-200Hz-Normally Closed
Wire type and power : DC 2-wire type 12-24VDC @(=)
Sensing side diameter : M18
Sensing distance : 14mm
Installation : Non-shield(non-flush)
Standard sensing target : 40×40×1mm(iron)
Response frequency : 200Hz
Cảm Biến Tiệm Cận Autonics PRD18-14DN-M18-14mm-200Hz-NPN Normally Open
Wire type and power : DC 3-wire type 12-24VDC @(=)
Sensing side diameter : M18
Sensing distance : 14mm
Installation : Non-shield(non-flush)
Standard sensing target : 40×40×1mm(iron)
Response frequency : 200Hz
Cảm Biến Tiệm Cận Autonics PRD18-14DP-M18-14mm-200Hz-PNP Normally Open
Wire type and power : DC 3-wire type 12-24VDC @(=)
Sensing side diameter : M18
Sensing distance : 14mm
Installation : Non-shield(non-flush)
Standard sensing target : 40×40×1mm(iron)
Response frequency : 200Hz
Cảm Biến Tiệm Cận Autonics PRDT18-14DO-M18-14mm-200Hz-Normally Open
Wire type and power : DC 2-wire type 12-24VDC @(=)
Sensing side diameter : M18
Sensing distance : 14mm
Installation : Non-shield(non-flush)
Standard sensing target : 40×40×1mm(iron)
Response frequency : 200Hz
Cảm Biến Tiệm Cận Autonics PRD18-7DN-M18-7mm-300Hz-NPN Normally Open
Wire type and power : DC 3-wire type 12-24VDC @(=)
Sensing side diameter : M18
Sensing distance : 7mm
Installation : Shield(flush)
Standard sensing target : 20×20×1mm(iron)
Response frequency : 300Hz
